master RT module
rear panel features
left, right, and mono output XLR ’s
This group of three balanced male XLR jacks carries the left,
right and mono output signals. These outputs are controlled by the
left, right and mono output faders.
see—left, right, and mono masters
hearing assist output
This single balanced male XLR carries a mono signal that is made up of
a sum of the left and right MASTER outputs.When the LCR TO OUT switch is
depressed, the center/mono output signal is included with the summed left
and right signal that appears at this jack.
This output does not have a designated level control.The summed signal is
derived after the left, right and mono (when the
LCR TO OUT switch is
depressed) MASTER faders.
left and right alternate output XLR ’s
This pair of balanced male XLR connectors carries the left and right
ALT OUT signals.These outputs are controlled by the ALT OUT level control.
see—left and right alternate output, front-panel description
left and right monitor output XLR ’s
XLR OUT carries the left and right MONITOR signals.These outputs are
controlled by the MONITOR level control.
see—monitor, front-panel description
