mono input module
rear panel features
direct out 1/4" TRS jack
The input channel's signal is available at this output jack.The
default signal routing is derived post-fader, post-eq and post-mute.This
output jack is ground-compensated.
insert points
Separate 1/4" TRS jacks provide the facilities for inserting an external sig-
nal processor into the signal path of the input channel.
insert send
This jack serves as an output for connection to the input of a
signal processor. The signal is derived after the mic preamp and HPF but
before the eq section. Plugging a 1/4" TRS plug into this jack does not break
the signal flow of the channel.This output jack is ground-compensated.
insert return
The output of a signal processor is fed to this jack. It can accept
a balanced or unbalanced signal and is located pre-eq. Plugging a 1/4" TRS
plug into this jack does break the signal flow of the channel.
balanced line-in jack—Bal Line In
Line-level signals, balanced or unbalanced, may be brought into
the input channel through this jack.The LINE switch must be depressed for
this jack to be active.
balanced mic-in xlr connector—Bal Mic In
This balanced female XLR accepts a low-impedance microphone
signal, or a line-level signal, depending on position of the LINE switch on
the front panel.
see—mono input module, phantom power, line
In situations where
the preamp circuitry is
not needed, the Insert
Return can be used as the
channel’s input.
For example, when using an
expensive tube mic preamp.
+
The insert send can
also be used as an
additional channel output
when s pre-EQ signal is
needed.
+
