Power supply, X-eight owner’s manual, Hs master rear-panel – Peavey X-Eight HS User Manual
Page 142: Rt group rear-panel, Model 5a power supply specifications, P. 142
p. 142
X-Eight owner’s manual
power supply
HS master rear-panel
DC In
Alt R Out
Alt L Out
Insert
Send
Return
Right
Out
Insert
Send
Return
Left
Out
In
In
RT group rear-panel
S
e
n
d
R
e
t
u
r
n
S
e
n
d
R
e
t
u
r
n
DC In
Group 5 Out
Group 6 Out
I
n
s
e
r
t
I
n
s
e
r
t
model 5A power supply
specifications
+18
V
@ 5
A DC
-18
V
@ 5
A DC
+12
V
@ 4
A DC
+48
V
@ 0.75
A DC
t
wo Hirose JR16RK-7S connectors on rear
connector meets JIS C 5432 standard
g
rey polyurethane outer jacket, 15 feet long
seven-way, 14-gauge stranded conductors
rated 600 volts, 80 degrees C
UL and CSA approved
Hirose JR16PK-7S and JR16PK-7P connectors fitted
90 to 250 volts
@
4.5 amps maximum
universal AC input voltage. No changes needed
0.5 amps idle
IEC 320 C-13 3-pin 15 amp recepticle
removable IEC type
with country-specific mains plug fitted
UL, CSA, and CE
two-
space 19 inch rack mount unit
3.5
inches tall, 17 inches wide, 12 inches deep.
weight: 18 pounds
output power
DC
out recepticle
DC
out cable
AC
mains power supply
AC
mains
recepticle cable
approvals
chassis
8
