group RT module
aux / group assignment features
aux sends 5–8
This section is used to send signals to AUXES 5 through 8.The aux signals
can originate from the TAPE - IN section or the GROUP section, pre- or post-
fader depending on settings of the switches below.
group-to-aux assignment— GROUP TO AUX
AUX SENDS 5–8 receive signals from the TAPE RETURN section, directly
after the TAPE RETURN level control.
AUX SENDS 5–8 receive signals from the GROUP section, directly after
the GROUP fader.
aux stereo 5/6 and 7/8
The default configuration for AUXES 5,6,7 and 8 is mono.These switches con-
figure the odd / even (5/6 and 7/8) AUX pairs as stereo sends.
The ODD - AUX becomes the PAN control and the EVEN - AUX becomes the LEVEL
control.
corresponding AUXES are configured as individual mono sends.
corresponding AUXES are configured as LEVEL and PAN for stereo oper-
ation.
aux pre-fader 5/6 and 7/8—PRE
The default signal source for the AUX SENDS is post-fader.These switches
are used for selecting the pre-fader signal for their respective AUXES .
corresponding AUX SENDS are post-mute and post-fader.
corresponding AUX SENDS are post-mute and pre-fader.
