group HS module
rear panel features
group output
This balanced male XLR connector carries the GROUP output signal.
see—group fader, front-panel description
group insert point
Separate 1/4" TRS jacks provide the ability to insert an external signal
processor into the signal path of the GROUP .
group insert send
This output connects to the input of an external signal proces-
sor. The signal is derived after the group-summing amplifier.
This output is ground compensated.
group insert return
This balanced input accepts a signal from the output of an
external signal processor. It accepts either balanced or unbalanced signals.
Plugging a 1/4" plug
into this jack does not
break the internal signal
flow of the Group.
+
Plugging a 1/4" plug
into this jack breaks
the signal flow
of the Group.
+
