master HS module
output EQ features
low frequency—LF
Selectable frequency range of 20Hz to 400Hz.
The response is bell-shaped with a fixed Q of 1.5.
15 dB boost/cut.
equalizer— EQ ON
Equalizer is on. This switch can be used to make A/B comparisons
between flat and eq’d signals.
left, right, mono equalization— EQ TO LEFT, TO RIGHT, TO MONO
These three switches select the signals fed to each of the first three
eq’s on the first three master sub-modules.The fourth MASTER sub-module
does not include a switch because its source is always MATRIX 4 .
MATRIX 1–3 are fed to the first three eq’s.
left, right and/or mono are fed to the first three eq’s.
