master HS module
rear panel features
left and right alternate output XLR ’s
This pair of balanced male XLR connectors carries the left and right
ALT OUT signals.These outputs are controlled by the ALT OUT level control.
see—left and right alternate output, front-panel description
XLR output jack on monitor
This pair of ground compensated 1/4" TRS jacks carries the left and right
MONITOR signals.These outputs are controlled by the MONITOR level con-
trol.
see—monitor, front-panel description
matrix 1–8 output XLR ’s
This group of four balanced male- XLR connectors carries the MATRIX
1–8 output signals.These outputs are controlled by their respective MATRIX
OUTPUT level controls.
see—matrix, front-panel description
left, right and mono output XLR ’s
This group of three balanced male- XLR connectors carries the left,
right and mono output signals. These outputs are controlled by the left,
right and mono output faders.
see—left, right, and mono masters, front-panel description
5
