master HS module
left and right level features
left and right master faders
These faders govern the main left and right output levels.
signal/peak LED—SIG/PEAK
This dual-color LED responds to the combined pre-fader stereo sig-
nal. It illuminates green with varying brightness in proportion to the audio
signal. When the signal approaches clipping, either pre or post fader, the
LED illuminates red.
solo
Pressing this switch will include (illuminated) or exclude (not illumi-
nated) the left and right signals from the console's SOLO system.The signals
are monitored in stereo.
see—master module, solo control system
