group RT module
group / aux level features
left-center-right—LCR
The post-fader GROUP signal is assigned to the left, right and
mono/center buses.Relative amounts of the signal fed to each bus is deter-
mined by the position of the
PAN pot.
pan
The PAN pot positions the signal within the stereo left/right field, or
between left-and-center or center-and-right in LCR mode.The signal must
be assigned as to LCR or the L-R bus in order for the
PAN control to have
any affect.
see—left-center-right and left/right assignment
mono assignment—M
The Group signal is assigned to the discrete Mono bus. When the
LCR button is depressed, this switch is bypassed.
left/right assignment—L-R
The Group signal is assigned to the main Left and Right output buses.
When the LCR button is depressed, this switch is bypassed.
safe preview LED
see—mono input module
group mute
see—mono input module
write-in label
This label may be written on with a marker, and later wiped clean with a
cloth moistened with isopropyl/rubbing alcohol.
signal/peak LED —SIG/PEAK
This dual-color LED responds to the pre-fader GROUP signal. It indi-
cates green with varying-brightness, in proportion to the audio signal.
When the signal approaches clipping, either pre or post fader, the LED
turns red.
group fader
The GROUP fader controls the level at which the GROUP signal is sent to any
assigned mix-buses or outputs.
LED
4
