master HS module
monitor output features
The MONITOR output section controls the audio feed for the console oper-
ator. Features are similar to those of ALT OUT section, except that the MON -
ITOR section is normally used to access the SOLO system as well as main
outputs.
Like the alternate output section, it provides the ability to assign the left
and right
MASTER signals to a designated pair of balanced male XLR con-
nectors on the rear-panel.
By utilizing the mode switches located below the LOCAL MONITOR OUTPUT
level control, these signals can be derived in a number of different ways. In
default mode (no switches depressed), the post-fader left and right
MASTER
signals are routed through LOCAL MONITOR level control and appear at the
MONITOR OUT balanced male XLR connectors on the rear-panel.
This feed is replaced by the SOLO signal when a SOLO is activated on the
console.
monitor-out level
see—alternate out
sum mono
see—alternate out
solo-off
When any of the SOLO switches on the console are active, the SOLO
audio is routed in stereo through the MONITOR OUT level control and
appears at the left and right MONITOR OUT balanced male XLR connector
on the rear-panel.
This setting overrides the left and right feed to the MONITOR output.
When any of the SOLO switches on the console are active, the
MONITOR outputs are not affected.
monitor talkback —TALK TO MONITOR OUT
The TALKBACK system output is added to the left and right MONITOR
outputs.The level of the TALKBACK signal is set by the TALKBACK level con-
trol in the MASTER section.
