group RT module
rear panel features
matrix in 1–4
located on the back of the GROUP 1–4 block
These 1/4"TRS jacks accept balanced or unbalanced +4dBu line level sig-
nals.They act as external inputs for MATRIX 1–4 .
see—master module, MATRIX 1–4 front-panel description
midi in, midi out
located on the back of the GROUP 5–8 block
These jacks make it possible for the MICROPROCESSOR MUTE SYSTEM to be
part of a MIDI system. Program changes and certain system-exclusive tasks
can be carried out.
see—microprocessor mute system
midi in
Midi information is brought into the console and routed to the
Microprocessor controlled mute system.
midi out
Midi information being sent out by the Microprocessor-controlled Mute
system is available at this connector.
DC power-in
located on the back of the GROUP 5–8 block
This is where the powersupply cable gets connected to the console.
lamp dim
goose-neck lamps light-up at full-intensity.
goose-neck lamps light-up at medium-intensity.
meterbridge connector
This connector carries all of the required connections up to the meter-
bridge.
