p. 69
group RT module
rear panel features
tape/line-input jack
A +4dBu line-level signal,balanced or unbalanced,is brought in through this
jack.
see—tape-in, front-panel description
insert point
Separate 1/4" TRS jacks allow insertion of an external signal processor into
the signal path of the GROUP .
insert send
This ground-compensated output connects to the input of an
external signal processor. The signal is derived after the group-summing
amplifier.
insert return
This balanced input accepts a signal from the output of an
external signal processor. It accepts either balanced or unbalanced signals.
group output
This balanced male XLR connector carries the GROUP output
signal.This output is controlled by the GROUP output section.This signal is
monitored on the group meter.
see—group output, front-panel description
4
Plugging a 1/4" plug
into this jack does not
break the internal signal
flow of the Group.
+
Plugging a 1/4" plug
into this jack breaks
the signal flow
of the Group.
+
