master HS module
output EQ features
On the MASTER module block, the default sources for the four output eq’s
are the MATRIX 1–4 masters.
By using designated assignment switches, source for the first three output
eq’s can be switched over to the left, right and mono masters.The fourth
eq is always fed by
MATRIX 4 master.
All eq's feature five bands of equalization.
see—group HS module
high frequency—HF
15 db boost/cut at 12kHz—shelving response.
high-mid frequency—HM
15 db boost/cut.
selectable frequency range of 400Hz to 8 kHz.
The response is bell-shaped with a fixed Q of 1.5.
mid frequency—MID
15 db boost/cut.
selectable frequency range of 200Hz to 4 kHz.
The response is bell-shaped with a fixed Q of 1.5.
low-mid frequency—LM
15 dB boost/cut.
selectable frequency range of 100Hz to 2 kHz.
The response is bell-shaped with a fixed Q of 1.5.
