Peavey X-Eight HS - Manual (Page 121)

p. 121
master RT module
rear panel features
matrix 1–4 output XLR ’s
This group of four balanced male XLR connectors carries the MATRIX
1–4 output signals.These outputs are controlled by their respective MATRIX
output level controls.
see—matrix, front-panel description
auxiliary 1–8 output XLR ’s
This group of eight balanced male XLR connectors carries the AUX
1–8 output signals. These outputs are controlled by their respective AUX
output level controls.
see—aux master output , front-panel description
left, right, and mono insert points
Separate 1/4" TRS jacks provide the ability to insert external signal proces-
sor into the signal paths of the left, right and mono MASTERS .
insert sends—left, right, and mono
These jacks connect to the input of signal processors.The sig-
nals are ground compensated.
insert returns—left, right, and mono
These jacks connect to the outputs of a signal processors.They
can accept balanced or unbalanced signals.
6
Plugging a 1/4" plug
into this jack does not
break the internal signal
flow of the respective Left,
Right, and Mono Masters.
+
Plugging a 1/4" plug
into this jack breaks
the signal flow
of the respective Left, Right,
and Mono Masters.
+
