group HS module
rear panel features
auxiliary 1–8 output XLR’s
This balanced male XLR connector carries the AUX output signal.
These outputs are controlled by their respective AUX output level controls.
see—aux section, front panel description
aux insert point
Separate 1/4" TRS jacks provide the ability to insert an external signal
processor into the signal path of the AUX .
aux insert send
This output connects to the input of an external signal proces-
sor. The signal is derived after the AUX -summing amplifier.
This output is ground compensated.
aux insert return
This balanced input accepts a signal from the output of an
external signal processor. It accepts either balanced or unbalanced signals.
group inputs 1–8
These 1/4" TRS jacks accept balanced or unbalanced line-level signals.
They act as external inputs for GROUPS 1–8.
lamp dim
Goose-neck lamps light-up at full intensity.
Goose-neck lamps light-up at medium intensity.
meterbridge connector
This connector carries all of the required connections up to the meter-
bridge.
3
Plugging a 1/4" plug
into this jack does not
break the internal signal
flow of the AUX BUS.
+
Plugging a 1/4" plug
into this jack breaks
the signal flow
of the Group.
+
