Peavey X-Eight HS - Manual (Page 139)

p. 139
microprocessor muting system
features
changing/reviewing utility settings
The UTILITY settings can be accessed by entering UTILITY mode. Once there,
the different parameters can be changed to suit user’s preferences. The
changes stay in effect until they are again modified by the user, or a
SYSTEM
RESET is performed which changes them all back to their default settings.
utility mode
1 Enter UTILITY mode:
Press the MICRO UTILITY button F, it is a latching switch, and the system
will stay in UTILITY mode while this button is depressed.The DISPLAY B
now shows the first parameter—uP of the parameter list.
2 Select a PARAMETER to edit
Use the UP / DOWN keys A to scroll through the list of available PARAMETERS .
3 View the current setting
Press the RECALL I button.The DISPLAY will change from showing the PARA -
METER to showing the PARAMETER ’s current setting.
4 Changing the setting
While the DISPLAY is showing parameter settings (not the parameter
itself), the UP / DOWN keys will scroll through the list of possible settings
for that parameter. Select the new-setting and press the RECALL button
again.The DISPLAY will briefly show ****, the displayed setting will be acti-
vated and the DISPLAY will go back to showing the parameter.
5 Exit UTILITY mode
When finished, press-and-release the MICRO UTILITY F key, the MUTE SYSTEM
returns to NORMAL mode with the new-settings in place.
The only way to get
back to showing the
parameter is to press the
RECALL button—even if
no-change is desired, the
RECALL button must be pressed.
Make sure the display is
showing the desired setting
when
RECALL is pressed. Then
return to step-two above,
and continue to select and
change parameters.
+
7
