p. 51
group HS module
group assignment features
mono assignment—from group— MONO
The GROUP signal is assigned to the discrete mono bus.
left/right assignment—from group— L/R
The GROUP signal is assigned to the main left and right output buses.
pan
The PAN pot is used to position the group signal within the stereo left
/ right field.The signal must be assigned to left and right in order for the
PAN control to have any effect.
safe preview LED
see—mono input module
mute
see—mono input module
3
