microprocessor muting system
features
channel mute controls
J— STATUS LED
This bi-color LED , associated with each controlled-mute, shows the con-
dition of that mute.
One-of-five possible states is possible:
1
OFF —The channel is not controlled by the MUTE CONTROLLER .
2
STEADY RED —The channel is being muted by a MUTE SCENE .
3
STEADY GREEN —The channel is in SAFE MODE , cannot be muted by any
scene.
4
FLASHING RED —The system is in EDIT / PREVIEW mode and the channel
is in the currently selected SCENE .
5 FLASHING GREEN —The system is in EDIT SAFE mode and the channel is
included in the SAFE SCENE .
6
MUTE SWITCH —This momentary-switch toggles the channel’s LOCAL
MUTE and is also used to assign/un-assign channels to MUTE and SAFE SCENES ,
when in the EDIT mode.
7
MUTE LED —This internal red- LED will illuminate whenever the channel
is muted, either locally or by a MUTE SCENE .
If a channel is already locally muted when a relevant MUTE SCENE is activat-
ed, this LED will remain lit. Two sources are now telling the channel to
mute: the LOCAL MUTE and the MUTE SCENE . If the MUTE switch K is pressed
once, the LOCAL MUTE will be cleared, but no apparent change will occur.
The MUTE LED L will still be lit, and the STATUS LED J will still be steady-red.
At this point there is only one source telling the channel to mute; the MUTE
SCENE . If the MUTE SCENE is then disabled, the channel will un-mute because
the LOCAL MUTE was previously cleared.
The user should be aware of this fact—the local mutes can toggle invisibly
behind a
MUTE SCENE . For an even number of presses on the MUTE switch
K, the LOCAL MUTE will return to its original state, an odd-number of press-
es will change the LOCAL MUTE to its opposite-state.
