group HS module
group
/
aux level features
signal/peak
LED
’s
This dual color
LED
responds to the pre-fader signal. It illuminates
green with varying brightness in proportion to the audio signal.When the
signal approaches clipping, either pre or post fader, the
LED
illuminates red.
talk to—fader 1–8
This switch adds the
TALKBACK
system output to the fader signal.The
level of the
TALKBACK
signal is set by the
TALKBACK
level control in the
MAS
-
TER
section.
fader
The fader normally controls the level at which the
GROUP
signal is sent to
any assigned buses or outputs. When the
REVERSE AUX
/
GROUP
switch is
selected, the fader controls the level of the
AUX
output.
solo
Pressing this switch will include or exclude the fader signal from the
console's
SOLO
system.
see—master module, solo control system
LED
3
