master RT module
alternate output features
The alternate output section allows assignment of the left and right master
signals to a separate pair of balanced male
XLR jacks on the rear-panel. By
utilizing the mode switches located below the ALT OUT level control, these
signals can be derived in a number of ways.
In default mode (no switches depressed), the post-fader left and right MAS -
TER signals are routed through the ALT OUT level control and appear at the
ALT OUT connectors.
alternate output level —ALT OUT
This control governs the levels that appear at the ALT OUT left and
right balanced XLR connectors on the rear-panel.
sum mono
The MAIN left and right signals are summed-to-mono before the alter-
nate output jacks. This summing does not affect the MAIN left and right out-
puts.
The MAIN left and right signals are routed in-stereo through the ALT
OUT level control and appear at the left and right ALT OUT balanced male
XLR connectors on the rear-panel.
pre
The signal feeding the ALT OUT section are taken before the main
left and right faders.
The signal feeding the ALT OUT section are taken after the MAIN
left and right faders.
talkback —TALK TO ALT OUT
The TALKBACK system output is added to the left and right ALT out-
puts.The level of the TALKBACK signal is set by the TALKBACK level control in
the MASTER section.
