master RT module
left / right master fader features
talkback left/right— TALK TO L/R
The TALKBACK system output is added to the left and right MASTER
output.The level of the TALKBACK signal is set by the TALKBACK level control
in the master section.
sum left/right— SUM L/R
The MAIN left and right signals are summed together as a mono sig-
nal and appear at the left and right output balanced-male XLR connectors
on the rear-panel.
The MAIN left and right signals appear in-stereo at the left and right
output balanced-male XLR connectors on the rear-panel.
signal /peak LED — SIG/PEAK
This dual-color LED responds to the combined pre-fader stereo sig-
nal. It illuminates green with varying brightness in proportion to the audio
signal. When the signal approaches clipping, either pre or post fader, the
LED illuminates red.
left and right master faders
These faders govern the MAIN left and right output levels.
solo
Pressing this switch will include or exclude the left and right signals
from the console's SOLO system.The signals are monitored in stereo.
see—master module, solo control system
LED
6
