master HS module
matrix features
The X-Eight HS includes four MATRIX mixes. Each of these outputs can be
made up of signals from the eight GROUPS , left, right, mono and an external
source.
left, right, and mono levels— MATRIX 1–4
These level controls are used to mix the left, right, and mono signals
into the corresponding MATRIX .
post-fader—left, right, and mono
These three post-fader switches determine whether the left, right and
mono
MASTER faders have any effect on signals that available to MATRIX 1–4 .
post-left, post-right, post-mono
The left, right and/or mono fader settings have no effect on the LEFT -,
RIGHT - and/or MONO - TO - MATRIX 1–4 level controls.
The left, right and/or mono faders are introduced into the signal
paths. When the left, right and/or mono are muted, the corresponding
MATRIX 1–4 level controls are also muted.
external input levels— MATRIX 1–4
These level controls are used to mix the external MATRIX input signals
into the corresponding matrix.The external MATRIX input connectors are
located on the rear-panel of the MASTER module.
external matrix routing— MTX 1 IN TO ALL
This switch routes the signal from the external MATRIX input 1 jack to
the external MATRIX 1–4 input level controls.This way,a single external input
can be added to each of the four matrices.
When this switch is down, the external MATRIX input jacks 2, 3 and 4 are
disabled.
