master RT module
matrix level control features
matrix 1–4 levels—left, right, and mono
These level controls mix the left, right and mono signals into the cor-
responding matrix.
external matrix 1–4 input levels controls
These level controls are used to mix the external MATRIX input signals
into the corresponding matrix.The external MATRIX input connectors are
located on the rear-panel of the MASTER module.
MTX 1-to-all
This switch routes the signal from the external MATRIX input-1 jack to
the external MATRIX input-level controls 1–4. This way, a single external
input can be added to each of the four matrices.
When this switch is down, the external MATRIX input jacks 2, 3 and 4 are
disabled.
