Flex-MuxOneNAND4G(KFM4GH6Q4M-DEBx)
- 46 -
FLASH MEMORY
Flex-MuxOneNAND8G(KFN8GH6Q4M-DEBx)
Flex-MuxOneNAND16G(KFKAGH6Q4M-DEBx)
Burst Length (BL)
Host must follow burst length set by BL when reading data in synchronous burst read.
NOTE :
1) In case of BootRAM : Main=512word, Spare=16word
In case of DataRAM : Main=1Kword, Spare=32word
Burst Length (BL) Information[11:9]
Error Correction Code (ECC) Information[8]
RDY Polarity (RDYpol) Information[7]
INT Polarity (INTpol) Information[6]
BL Burst Length(Main) Burst Length(Spare)
000 Continuous(Default) 1)
001 4 words
010 8 words
011 16 words
100 32 words N/A
101~111 Reserved
Item Definition Description
BL Burst Length
Specifies the size of the burst length during a synchronous
linear burst read and wrap around. And also burst length during a
synchronous linear burst write
Item Definition Description
ECC Error Correction Code Operation
0 = with correction (default)
1 = without correction (bypassed)
Item Definition Description
RDYpol RDY signal polarity
1 = high for ready (default)
0 = low for ready
INTpol INT bit of Interrupt Status Register INT Pin output
0
0 (busy) High
1 (ready) Low
1 (default)
0 (busy) Low
1 (ready) High
