Flex-MuxOneNAND4G(KFM4GH6Q4M-DEBx)
- 33 -
FLASH MEMORY
Flex-MuxOneNAND8G(KFN8GH6Q4M-DEBx)
Flex-MuxOneNAND16G(KFKAGH6Q4M-DEBx)
2.7.5 External Memory Spare Area Assignment
Buf.
Word
Address
Byte
Address
F E D C B A 9 8 7 6 5 4 3 2 1 0
BootS 0 8000h 10000h BI(Bad block Information )
8001h 10002h
Managed by internal ECC logic
8002h 10004h
8003h 10006h
4bit ECC parity values
8004h 10008h
8005h 1000Ah
8006h 1000Ch
8007h 1000Eh
BootS 1 8008h 10010h BI(Bad block Information )
8009h 10012h
Managed by internal ECC logic
800Ah 10014h
800Bh 10016h
4bit ECC parity values
800Ch 10018h
800Dh 1001Ah
800Eh 1001Ch
800Fh 1001Eh
DataS
0_0
8010h 10020h BI(Bad block Information )
8011h 10022h
Managed by internal ECC logic
8012h 10024h
8013h 10026h
4bit ECC parity values
8014h 10028h
8015h 1002Ah
8016h 1002Ch
8017h 1002Eh
DataS
0_1
8018h 10030h BI(Bad block Information )
8019h 10032h
Managed by internal ECC logic
801Ah 10034h
801Bh 10036h
4bit ECC parity values
801Ch 10038h
801Dh 1003Ah
801Eh 1003Ch
801Fh 1003Eh
Equivalent to 1word of NAND Flash
