Flex-MuxOneNAND4G(KFM4GH6Q4M-DEBx)
- 42 -
FLASH MEMORY
Flex-MuxOneNAND8G(KFN8GH6Q4M-DEBx)
Flex-MuxOneNAND16G(KFKAGH6Q4M-DEBx)
Sector allocation according to BSC(CASE1 : FSA=00)
Sector allocation according to BSC(CASE2 : FSA=01)
Sector allocation according to BSC(CASE3 : FSA=10)
Sector allocation according to BSC(CASE4 : FSA=11)
* The first sector from Flash(The first sector is determined by FSA. In case of FSA=01[CASE2], the first sector is Sector1.)
is transferred to the 1st sector(sector0) of DataRAM0, and the other sectors are transferred sequentially.
Sector0 Sector1 Sector2 Sector3 Sector4 Sector5 Sector6 Sector7
Sector0
Sector0 Sector1
Sector0 Sector1 Sector2
Sector0 Sector1 Sector2 Sector3
Sector0 Sector1 Sector2 Sector3 Sector4
Sector0 Sector1 Sector2 Sector3 Sector4 Sector5
Sector0 Sector1 Sector2 Sector3 Sector4 Sector5 Sector6
BSC = 000
BSC = 001
BSC = 010
BSC = 011
BSC = 100
BSC = 101
BSC = 110
BSC =111
Sector0
Sector0 Sector1
Sector0 Sector1 Sector2
BSC = 001
BSC = 010
BSC = 011
Sector1
Sector1 Sector2
Sector1 Sector2 Sector3
BSC = 001
BSC = 010
BSC = 011
Sector2
Sector2 Sector3
BSC = 001
BSC = 010
Sector3 BSC = 001
