Flex-MuxOneNAND4G(KFM4GH6Q4M-DEBx)
- 35 -
FLASH MEMORY
Flex-MuxOneNAND8G(KFN8GH6Q4M-DEBx)
Flex-MuxOneNAND16G(KFKAGH6Q4M-DEBx)
NOTE :
In case of ‘with ECC’ mode, Flex-MuxOneNAND automatically generates ECC code for both main and spare data of memory during program operation, but does
not update ECC code to spare bufferRAM during load operation.
Buf.
Word
Address
Byte
Address
F E D C B A 9 8 7 6 5 4 3 2 1 0
DataS 1_3 8048h 10090h BI(Bad block Information )
8049h 10092h
Managed by internal ECC logic
804Ah 10094h
804Bh 10096h
4bit ECC parity values
804Ch 10098h
804Dh 1009Ah
804Eh 1009Ch
804Fh 1009Eh
Equivalent to 1word of NAND Flash
