68 Cluster Platform 4500/3 User’s Guide • July 2001
TABLE C-8 Ethernet Hub Connections
From Device From Location To Device To Location
Cable
Length/Type
Ethernet hub Port No. 0 Disk array No. 1
(node 1) 10BASE-T port RJ-45
Ethernet hub Port No. 1 Disk array No. 2
(node 2) 10BASE-T port RJ-45
Ethernet hub Port No. 5 Administration
network RJ-45
Ethernet hub Port No. 7 Network port Terminal
concentrator RJ-45
