Figure24 cluster platform rack placement – Sun Microsystems 4500/3 User Manual
Page 26
14
Cluster Platform 4500/3 User’s Guide • July 2001
FIGURE 2-4
Cluster Platform Rack Placement
D130 boot disk No. 4
D130 boot disk No. 3
D130 boot disk No. 2
D130 boot disk No. 1
System No. 2 (cluster node 2)
System No. 1 (cluster node 1)
Air baffle
Air baffle
Expansion cabinet
Ethernet hub
FC-AL hub No. 1 and hub No. 2
Management server
Disk array No. 2 (mirror)
Disk array No. 1 (data)
Terminal concentrator (not shown)
