Appendix C
Connections Within the Cluster Platform 4500/3
67
TABLE C-5
Terminal Concentrator to Management Server and Cluster Nodes
Connections
From Device
From Location
To Device
To Location
Cable
Length/Type
Terminal
concentrator
Serial port 1
Management server
Serial port A
Serial cable
Terminal
concentrator
Serial port 2
System No. 1 (node 1)
Serial port A
RJ-45/DB-25
serial
Terminal
concentrator
Serial port 3
System No. 2 (node 2)
Serial port A
RJ-45/DB-25
serial
TABLE C-6
Node to Node Connections
From Device
From Location
To Device
To Location
Cable
Length/Type
System No. 1
(node 1)
System board
No. 1,
SBus 0, qfe0
System No. 2
(node 2)
System board
No. 1,
SBus 0, qfe0
Null Ethernet
System No. 1
(node 1)
System board
No. 5, SBus 0,
qfe4
System No. 2
(node 2)
System board
No. 5, SBus 0,
qfe4
Null Ethernet
System No. 2
(node 2)
System board
No. 1, SBus 0,
qfe0
System No. 1
(node 1)
System board
No. 1, SBus 0,
qfe0
Null Ethernet
System No. 2
(node 2)
System board
No. 5, SBus 0,
qfe4
System No. 1
(node 1)
System board
No. 5, SBus 0,
qfe4
Null Ethernet
TABLE C-7
Ethernet Cables to Production Network Connections
From Device
From Location
To Device
To Location
Cable
Length/Type
System No. 1
(node 1)
System board No. 1,
onboard Ethernet
hme0
Production
Network
Variable length
Ethernet
System No. 1
(node 1)
System board No. 3,
onboard Ethernet
hme1
NAFO
Failover
Variable length
Ethernet
System No. 2
(node 2)
System board No. 1,
onboard Ethernet
hme0
Production
Network
Variable length
Ethernet
System No. 2
(node 2)
System board No. 3,
onboard Ethernet
hme1
NAFO
Failover
Variable length
Ethernet
