Vig390s Motherboard Manual V1.0 97
Boot / Hard Drives Sub-menu
This menu allows the HDD boot order to be configured
Figure 52: Boot / Hard Drives sub menu
A detailed description of each of the features is given in the following table.
Table 53: Boot / Hard Drives Sub-menu
Feature Options Description
1st Boot Device • 1 st HDD
detected[Default]
• 2 nd HDD detected
• 3 rd HDD detected
• Disabled
The first boot HDD.
Allows the 1
st boot device to be changed to another
detected HDD as desired
2 nd Boot Device • 1 st HDD detected
• 2 nd HDD
detected[Default]
• 3 rd HDD detected
• Disabled
The second boot HDD.
Allows the 2
nd boot device to be changed to another
detected HDD as desired
3 rd Boot Device • 1 st HDD detected
• 2 nd HDD detected
• 3 rd HDD
detected[default]
• Disabled
The third boot HDD.
Allows the third boot device to be changed to another
detected HDD as desired
Note: if les HDD’s are installed then a 3 rd or 2 nd boot device will not be shown; if
more HDD’s are installed then a 4 th etc. boot devices will be shown.
Hard Drives
1st Boot Device [PM-HDS722512VLAT20]
2nd Boot Device [3M-HDS724040KLSA80]
3rd Boot Device [4M-HDS724040KLSA80]
Specifies the
Boot Device
Priority sequence
from the available
Hard Drives.
← Select Screen
↑↓ Select Item
+- Change Field
Tab Select
Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.53 (C) Copyright 1985-2002, American Magatrends, Inc.
BIOS SETUP UTILITY
Main Advanced Power Boot Exit
