Vig390s Motherboard Manual V1.0 111
2 USBP0# [USBP1#]
3 USBP0 [USBP1]
4 Ground
Table 73: Serial Port Connectors
Pin Signal Name
1 DCD
2
Serial In #
3 Serial Out #
4 DTR#
5 Ground
6 DSR
7 RTS
8 CTS
9 RI
Table 74: Audio Line Out Connector
Pin Signal Name
Sleeve Ground
Tip
Audio Left Out
Ring Audio Right Out
Table 75: Audio Line In Connector
Pin Signal Name
Sleeve Ground
Tip
Audio Left In
Ring Audio Right In
Table 76: Audio Mic In Connector
Pin Signal Name
Sleeve Ground
Tip Mono
In
Ring Electret Bias Voltage
Table 77: Parallel Port Connector
Pin Signal Name Pin Signal Name
1 Strobe# 14 Auto Feed#
2 Data bit 0 15 Fault#
3 Data bit 1 16 INIT#
4 Data bit 2 17 SLCT IN#
5 Data bit 3 18 Ground
6 Data bit 4 19 Ground
7 Data bit 5 20 Ground
8 Data bit 6 21 Ground
9 Data bit 7 22 Ground
10 ACK# 23 Ground
11 Busy 24 Ground
12 Error 25 Ground
13 Select
