Vig390s Motherboard Manual V1.0

LBA/ Large Mode • Disabled

• Auto [Default]

Displays whether automatic translation mode is
enabled from the hard disk
(This item is read only unless Type is set to User)

Block [Multi-sector
Transfer]

• Disabled
• Auto [Default]

Displays whether automatic multiple sector data
transfers are enabled
(This item is read-only unless Type is set to User)

PIO Mode

• Auto [Default]
• 0
• 1
• 2
• 3
• 4

Sets the PIO mode
(This item is read-only unless Type is set to User)

DMA Mode

• Auto [Default]
• SWDMA0
• SWDMA1
• SWDMA2
• MWDMA0
• MWDMA0
• MWDMA1
• MWDMA2
• UDMA

• UDMA

Specifies the DMA mode for the drive

Auto = Auto-detected
SWDMAn = Single Word DMAn
SWDMAn = Multi Word DMAn
UDMAn = Ultra DMAn

(This item is read-only unless Type is set to User)

SMART
Monitoring

• Auto [Default]
• Disabled
• Enabled

Enables/disables S.M.A.R.T. (Self Monitoring Analysis
and Reporting Technologies)
(This Item is read-only unless Type is set to User)

32Bit Data
Transfer

• Disabled

[Default]

• Enabled

Enables/disables 32Bit data transfer
(This Item is read-only unless Type is set to User)
