Intel Vig390s User Manual
Page 15
Vig390s Motherboard Manual V1.0
14
Single Channel (Asymmetric) Mode Configurations (Illustration only)
Note:
Dual channel (Interleaved) mode configurations provide the highest memory
throughput. Figure 7 shows a single channel configuration using one DIMM. In this
example, only the DIMM1 (black) socket of Channel A is populated. Channel B is not
populated.
256MB
Figure 7: Single Channel (Asymmetric) Mode Configuration with One DIMM
