Vig390s Motherboard Manual V1.0 107
Connector Signal Details
Table 57: Wake on Ring Connector
Pin Signal Name
1 Ground
2 RINGA#
Table 58: Wake on LAN Connector
Pin Signal Name
1 +5 VSB
2 Ground
3 WOL
Table 59: Fan 3 Connector
Pin Signal Name
1 Ground
2
FAN_CTRL (+12 V)
3 FAN_SEN*
Table 60: Auxiliary Line In Connector
Pin Signal Name
1 Left Line In
2 Ground
3 Ground
4
Right Line In (monaural)
Table 61: Telephony Connector
Pin Signal Name
1 Audio in (monaural)
2 Ground
3 Ground
4
Mic pre-amp out (to modem)
Table 62: CD Audio Connector
Pin Signal Name
1 CD_IN-Left
2 Ground
3 Ground
4 CD_IN-Right
Table 63: Chassis Intrusion Connector
Pin Signal Name
1 Ground
2 CHS_SEC
Table 64: Fan 2 Connector
Pin Signal Name
1 Ground
2
FAN_CTRL (+12 V)
3 FAN_SEN*
* If the optional management extension hardware is not available, pin 3 is ground.
