Vig390s Motherboard Manual V1.0 78
Advanced / USB Configuration Sub-menu
This menu allows USB controller configuration
Figure 39: Advanced / USB Configuration sub menu
A detailed description of each of the features is given in the following table.
Table 40: Advanced / USB Configuration sub menu
Feature Options Description
USB Function • Disabled
• All USB Ports
[Default]
• 2 USB Ports
Allows enable or disable the USB function.
Legacy USB
Support • Disabled
• Enabled
• Auto [Default] Allows the system to detect the presence of USB
devices at
start up. If detected, the USB controller
legacy mode is enabled. If no USB device is detected,
the legacy USB support is disabled.
USB 2.0 controller • Enabled [Default]
• Auto Disabled
Allows you to enable or disable the USB 2.0
controller.
USB Controller
Mode • Hi Speed
[Default]
• Full Speed
Allows the USB 2.0 controller mode to HiSpeed (480
Mbps) or
FullSpeed (12 Mbps).
USB Configuration
Module Version – 2.23.2-7.4
USB Devices Enabled; None
USB Function [All USB Ports]
Legacy USB Support [Auto]
USB 2.0 controller [Enabled]
USB Controller Mode [HiSpeed]
Enables USB Host
Controller.
← Select Screen
↑↓ Select Item
+- Change Field
Tab Select
Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.53 (C) Copyright 1985-2002, American Magatrends, Inc.
BIOS SETUP UTILITY
Main Advanced Power Boot Exit
