Vig390s Motherboard Manual V1.0

Main / Secondary P-ATA IDE Master or Slave Sub-menu

This menu shows a detected hard drive or CD-ROM drive features and allows
configuration settings to be made. The example is of a CD-ROM drive.

Figure 33:

Main / Secondary P-ATA IDE Master or Slave sub menu

A detailed description of each of the features is given in the following table.

Table 34: Main / Secondary P-ATA IDE Master or Slave Sub-menu

Feature Options

Description

Device

none

Displays detected device connected

Vendor

none

Displays the detected vendor name and model of
device

LBA Mode

none

Displays the detected translation mode or set by user

Block Mode

none

Displays the detected Block mode or set by user

PIO Mode

none

Displays the detected PIO mode or set by user

Async DMA

none

Displays the detected asynchronous DMA mode or
set by user

Ultra DMA

none

Displays the detected asynchronous Ultra DMA mode
or set by user

Type

• Not

Installed

• Auto [Default]
• CDROM
• ARMD

Specifies the IDE configuration mode for IDE devices
User allows capabilities to be changed
Auto fills-in capabilities from ATA/ATAPI devices

Secondary P-ATA IDE Master

Device : ATAPI CD-ROM
Vendor : SONY CD-RW CRX230ED
LBA Mode : Supported
PIO Mode : 4
Async DMA : Multi DMA Word-2
Ultra DMA : Ultra MDA2

Type

[Auto]

PIO Mode

[Auto]

DMA Mode

[Auto]

Select the type
of device connected
to the system.

←

Select Screen

↑↓ Select

Item

+- Change Field
F1

General Help

F10

Save and Exit

ESC Exit

BIOS SETUP UTILITY

Main
