Vig390s Motherboard Manual V1.0

Advanced / PCI PnP Sub-menu

This menu allows advanced configuration of PCI BUS

Figure 46a: Advanced / PCI PnP Sub-Menu

Figure 46b: Advanced / PCI PnP Sub-menu (use arrow keys to view all of menu items as above)

Advanced PCI/PnP Settings

Warning: Setting wrong values in bellow sections
May cause system to malfunction.

Plug And Play O/S

[No]

PCI Latency Timer

[64]

Allocate IRQ To PCI VGA

[Yes]

Pallet Snooping

[Disabled]

PCI IDE BusMaster

[Enabled]

Offboard PCI/ISA IDE Card

[Auto]

IRQ-3 assigned to

[PCI Device]

IRQ-4 assigned to

[PCI Device]

IRQ-5 assigned to

[PCI Device]

IRQ-7 assigned to

[PCI Device]

IRQ-9 assigned to

[PCI Device]

IRQ-10 assigned to

[PCI Device]

IRQ-11assigned to

[PCI Device]

IRQ-14 assigned to

[PCI Device]

NO: lets the BIOS
configure all the
devices in the system.
Yes: lets the
Operating system
Configure Plug and
Play (PnP) devices not
required for boot if
your system has a Plug
and Play operating
system.

←

Select Screen

↑↓ Select

Item

+- Change Field
F1

General Help

F10

Save and Exit

ESC Exit
