not be changed or an item that may be configured and permanently changed. To
change each field follow the navigation key guide either Press
or <+> keys to change selected filed. To save the desired change/s the “Save and
Exit” option is selected by either F10 directly or via the exit menu and then selecting
“Save and Exit”.
Navigation keys
The keys that are indicated are used to select items change configuration fields,
save and exit the BIOS setup utility
Figure 30: Pop up Windows
Pop up Window appears for options when
↑” and “↓”
arrows keys to select an option and enter to set the option.
System Time
[12:31:32]
System date
[Thu 01/20/2005]
Legacy Diskette A
[1.44M , 3.5 in.]
8
Primary P-ATA IDE Master :
[HDS722512VLAT20]
8
Primary P-ATA IDE Slave :
[Not Detected]
8
Secondary P-ATA IDE Master:
[Sony CD-RW CRX]
8
Secondary P-ATA IDE Slave :
[Not Detected]
8
S-ATA 1 :
[HDS724040KLSA80]
8
S-ATA 2 :
[HDS724040KLSA80]
8
IDE Configuration
8
System Information
Use
[ENTER] , [TAB]
or
[Shift-TAB] to
select a field.
Use
[+] or [-] to
configure system time.
←
Select Screen
↑↓ Select
Item
+- Change Field
Tab Select
Field
F1
General Help
F10
Save and Exit
ESC Exit
v02.53 (C) Copyright 1985-2002, American Magatrends, Inc.
BIOS SETUP UTILITY
Main
Advanced Power Boot Exit
Options
Disabled
360K , 5.25 in.
1.2M , 5.25 in.
720K , 3.5 in.
1.44M , 3.5 in.
2.88M , 3.5 in.
