Advanced / CPU Configuration Sub-menu
This manus configures the CPU settings
Figure 41: Advanced / CPU Configuration Sub-Menu
A detailed description of each of the features is given in the following table.
Table 42: Advanced / CPU Configuration Sub-menu
Feature Options Description
CPU Lock Free • Auto [Default]
• Disabled
• Enabled Not supported, allows setting CPU clock to lower
than fixed value
not recommended.
Hyper Thread
Technology • Disabled
• Enable [Default]
Allows enable or disable the processor Hyper-
Threading Technology.
Max CPUID Value
Limit • Disabled
[Default]
• Enable
Enabled allows legacy operating systems to boot even
without support for CPUs with extended CPUID
functions.
Execute Disable
Function • Disabled
[Default]
• Enable
Allows enable or disable the processor execute disable
function.
Enhanced C1
Control • Auto [Default]
• Disabled Allows enable or disable the processor Enhanced C1
control
function.
CPU Internal
Thermal Control • Auto [Default]
• Disabled CPU Internal Thermal Control.
It is not recommended to disable this feature.
Configure Advance CPU settings
Manufacturer: Intel
Brand String: Intel(R )Xeon (TM) CPU 3.6GHz
Frequency : 3600 MHZ
FSB Speed : 800 MHz
Ratio Status: Locked
Ratio Actual Value : 18
CPU Lock Free [Auto]
Hyper Thread Technology [Enabled]
Max CPUID Value Limit [Disabled]
Execute Disable Function [Disabled]
Enhanced C1 Control [Auto]
CPU Internal Thermal Control [Auto]
Intel (R) SpeedStep (tm) tech. [Automatic]
Unlock locked CPU and
let is run at lower
multiplier setting.
