Intel Vig390s User Manual
Page 46
Vig390s Motherboard Manual V1.0
45
Once both heatsinks are secured locate and connect the fna cables of each Heatsink
to the appropriate CPU fan header, for CPU 1 “CPU FAN” and for CPU2 “CPU FAN
2”.
Figure 26: Two Heatsinks fitted through MB
You should now have two CPU’s and Heatsink/s secured with fan cable/s connected
correctly.
