Vig390s Motherboard Manual V1.0

Main menu / IDE Configuration Sub-menu

This menu shows the IDE controller configuration.

Figure 34: IDE Configuration Sub-menu

A detailed description of each of the features is given in the following table.

Table 35: IDE Configuration Sub-menu

Feature Options

Description

Device

• Enhance Mode

[Default]

• Compatibly

Mode

Enhanced mode allows the translation of all P-ATA
and S-ATA port devices under Windows 2000 Pro and
Windows XP.
Compatibility is required for S-ATA devices under
DOS.

Enhanced mode
support On

• S-ATA [Default]

• P-ATA + S-ATA

• P-ATA

Defines the S-ATA and P-ATA ports translated under
enhanced mode as required.

Configure S-ATA
as RAID

•

Yes

•

No [Default]

RAID enable option for S-ATA devices
Once enabled devices are configured under controller
boot option during BIOS POST boot. Press + A
during BIOS post boot to configure RAID.

IDE Detect Time
Out (Sec)

•

35 [Default]

Hard drive pre delay time.

IDE Configuration

Onboard IDE Operate Mode

[Enhanced Mode]

Enhanced Mode Support On

[S-ATA]

Configure S-ATA as RAID

[No]

IDE Detect Time Out (Sec)

[35]

When in AHCI/RAID
Mode SATA
Connector is
forced to Negative
mode.

←

Select Screen

↑↓ Select

Item

+- Change Field
F1

General Help

F10

Save and Exit

ESC Exit

BIOS SETUP UTILITY

Main
