Vig390s Motherboard Manual V1.0 87
A detailed description of each of the features is given in the following table.
Table 47: Advanced / PCI PnP Sub-menu
Feature Options Description
Plug And Play O/S • NO [Default]
• Yes PnP play OS setting if set to “NO” the BIOS
configures system resources, otherwise resources are
set by PnP OS.
PCI Latency Timer • 32
• 64 [Default]
• 96
• 128
• 160
• 192
• 224
• 248 Allows the value in units of PCI clocks for the PCI
device latency timer register.
Allocate IRQ To PCI
VGA • Yes [Default]
• No When set to [Yes], BIOS assigns an IRQ to PCI VGA
card if the card
requests for an IRQ. When set to [No].
It is not recommended this is set to “NO”
Pallet Snooping • Disabled
[Default]
• Enabled
Support for legacy Video capture cards.
It is not recommended this is set to “Enabled”
PCI IDE BusMaster • Disabled
• Enabled [Default] PCI bus master control.
It is not recommended this is set to “Disabled”
Offboard PCI/ISA
IDE Card • Auto [Default]
• PCI
Slot1
• PCI Slot2
• PCI Slot3
• PCI Slot4
• PCI Slot5
• PCI Slot6
Allows assignment of a PCI slot to a PCI IDE card,
when required.
IRQ-3 assigned to
To
IRQ-15 assigned to • PCI Device
[Default]
• Reserved
When set to [PCI Device], the specific IRQ is free for use of
PCI/PnP devices. When set to [Reserved], the IRQ is
reserved for legacy ISA
devices.
DMA Channel 0
to
DMA Channel 7 • PCI Device
[Default]
• Reserved
When set to [PCI Device], the specific DMA channel is
free for use of PCI/PnP devices. When set to
[Reserved], the DMA channel is reserved for
Legacy ISA devices.
Reserved Memory
Size • Disabled
[Default]
• 16k
• 32k
• 64k
Allows you to set the reserved memory size.
Some adaptors with ROM options may require memory to
be reserved.
