Main / Primary P-ATA IDE Master or Slave Sub-menu

This menu shows a detected hard drive or CD-ROM features and allows
configuration settings to be made. The example is of a hard drive.

Figure 32: Main / Primary P-ATA IDE Master or Slave Sub-menu

A detailed description of each of the features is given in the following table.

Table 33: Main/Primary P-ATA IDE Master or Slave Sub-menu

Feature Options

Description

Device

none

Displays detected device connected

Vendor

none

Displays the detected vendor name and model of
device

LBA Mode

none

Displays the detected translation mode or set by user

Block Mode

none

Displays the detected Block mode or set by user

PIO Mode

none

Displays the detected PIO mode or set by user

Async DMA

none

Displays the detected asynchronous DMA mode or
set by user

Ultra DMA

none

Displays the detected Ultra DMA mode or set by user

SMART
Monitoring

none

Displays SMART monitoring support

Type

• Not

Installed

• Auto [Default]
• CDROM
• ARMD

Specifies the IDE configuration mode for IDE devices
User allows capabilities to be changed
Auto fills-in capabilities from ATA/ATAPI devices

Primary P-ATA IDE Master

Device : Hard Drive
Vendor : HDS722512VLAT20
Size : 123.5GB
LBA Mode : Supported
Block Mode : 16 Sectors
PIO Mode : 4
Async DMA : Multi DMA Word-2
Ultra DMA : Ultra MDA-5
SMART Monitoring: Supported

Type

[Auto]

LBA/Large Mode

[Auto]

Block [Multi-sector Transfer]

[Auto]

PIO Mode

[Auto]

DMA Mode

[Auto]

SMART Monitoring

[Auto]

32Bit Data Transfer

[Disabled]

Select the type
of device connected
to the system.

←
