MAP 0200: Optional Adapter or Dial Access Adapter Is Not Working
Note: See Figure 1-10 on page 1-3 or Figure 1-11 on page 1-4 for position of
adapter status LED.
001
Is the adapter green status LED on?
Yes No
002
Is the adapter firmly seated in the riser?
Yes No
003
Seat the adapter firmly in the riser, then go to Step 001.
004
Is the power cable connected correctly to the riser card, and the riser
card seated firmly in the socket?
Yes No
005
Connect the cables correctly and make sure the riser card is firmly in
the socket.
006
Test the power supply.
Is the power supply OK?
Yes No
007
Replace the power supply.
– Go to “MAP 0210: Verify Operation” on page 2-23.
008
Replace the riser card.
Go to “MAP 0210: Verify Operation” on page 2-23.
009
(Step 009 continues)
Chapter 2. Problem Determination 2-21
