Supported bit rates (in bps) are:
1200
2400
4800
9600
19 200
38 400
| The terminal speed must match the serial port speed.
Table A-2. Setup Attributes for the IBM 3151
Attribute Setting
Machine Mode 3151
Scroll JUMP
Auto LF OFF
Line Wrap OFF
Operating Mode ECHO
Word Length (bits) 8
Stop Bit 1
Turnaround Character CR
Line Control IPRTS
Break Signal (ms) 500
Send Null Suppress ON
IBM 3161 Setup Attributes
Activate setup mode in the IBM 3161 terminal by pressing the Ctrl and Setup keys.
The Ctrl key is located on the lower left of the keyboard. The Setup key is located
on the upper right of the keyboard. The terminal displays a setup attribute panel.
Change the attributes by moving the cursor to the various fields and typing over the
information in the field. Use Table A-3 to help you determine the settings for the
setup attributes.
Press Send to save the attributes on this panel.
Supported bit rates (in bps) are:
1200
2400
4800
9600
19 200
Table A-3. Setup Attributes for the IBM 3161
Attribute Setting
Machine Mode 3161
Operating Mode ECHO
Interface RS-232C
Line Control IPRTS
Turnaround Character CR
Stop Bit 1
Word Length (bits) 8
Response Delay (ms) 100
Break Signal (ms) 500
A-6 2210 Service and Maintenance
