Asm– Part
Index Number Units Description
1–1 NP Final Assembly
–1 NP Cover, Top
–2 4H7060 1 Cable, LED Panel
–3 4H8201 1 LED Panel, Models 121, 123, and 12T
–3 4H8202 1 LED Panel, Models 122, 124, and 12E
–3 4H8203 1 LED Panel, Models 125 and 127
–3 4H8204 1 LED Panel, Models 126 and 128
–4 1624743 2 Screw, Hex, M3 X 6 Lg
–5 92G8547 2 Bracket, Mounting
–6 92G8546 4 Screw, M4 X 8 Lg
–7 4H7088 2 Screw, M4 X 6 Lg
–8 92G8549 1 Bracket, Cable Management
–9 4H8211 1 Chassis, Model 121
–9 4H8212 1 Chassis, Model 122
–9 4H8213 1 Chassis, Model 123
–9 4H8213 1 Chassis, Model 12T
–9 4H8214 1 Chassis, Model 124
–9 4H8214 1 Chassis, Model 12E
–9 4H8215 1 Chassis, Model 125
–9 4H8216 1 Chassis, Model 126
–9 4H8217 1 Chassis, Model 127
–9 4H8218 1 Chassis, Model 128
–10 NP Cover, Chassis, Models 121, 123, and 12T
–10 NP Cover, Chassis, Models 122, 124, and 12E
–10 NP Cover, Chassis, Models 125 and 127
–10 NP Cover, Chassis, Models 126 and 128
–11 NP Cable, AC Connector
–12 1622346 1 Washer, Lock Ext T- 4.3 ID X 0.5 Th
–13 1622318 1 Washer, Lock Spr- 4.1 ID X 0.9 Thk
–14 1622403 1 Nut, Hex-M4 X 7 Flw X 3.2 Thk
–15 73G3485 4 Screwlock- 4-40
–15A 73G4036 1 Slide, Ethernet
–15B 73G4037 2 Screw, 4-40
–16 62X0388 2 Screwlock, 4-40
–17 72H3627 1 System Board, Model 121
–17 4H8192 1 System Board, Model 122
–17 72H3628 1 System Board, Model 123
–17 72H3628 1 System Board, Model 12T
–17 4H8194 1 System Board, Model 124
–17 4H8194 1 System Board, Model 12E
–17 4H8195 1 System Board, Model 125
–17 4H8196 1 System Board, Model 126
–17 4H8197 1 System Board, Model 127
–17 4H8198 1 System Board, Model 128
–18 1624743 AR Screw, Hex, M3 X 6 Lg
–19 4H8189 1 SIMM- 4 Meg
–19 4H8190 1 SIMM- 8 Meg
–19 41H7107 1 SIMM- 16 Meg
Appendix C. Parts Listing C-3
