Asm– Part
Index Number Units Description
3–3 NP Final Assembly
–1 NP Cover, Top
–2 13H8412 1 Cable, LED Panel
–3 1624743 4 Screw, Hex, M3 X 6 Lg
–4 1624743 9 Screw, Hex, M3 X 6 Lg
–5 41H7108 1 Flash SIMM- 4 MB
–5 72H5029 1 Flash SIMM- 8 MB
–6A 13H8803 1 Bracket, Mounting - Left
–6B 13H8804 1 Bracket, Mounting - Right
–7 4H7088 2 Screw, M4 X 6 Lg
–8 92G8549 1 Bracket, Cable Management
–9 41H7112 1 Chassis - Frame Top and Bottom Model 24T
–22 41H7113 1 Chassis - Frame Top and Bottom Model 24E
–23 41H7114 1 Chassis - Frame Top and Bottom Model 24M
–10 73G3485 4 Screwlock- 4-40
–11 73G4036 1 Slide, Ethernet
–12 73G3485 4 Screwlock- 4-40
–13 73G4037 4 Screw, 4-40
–14 41H7083 1 System Board, Model 24T
–14 41H7084 1 System Board, Model 24E
–14 41H7085 1 System Board, Model 24M
–15 13H8805 NP Cable, AC Connector
–16 41H7103 1 Reset Card Assembly
–17 92G8546 4 Screw, M4 X 8 Lg
–18 41H7110 1 Fan Asm
–19 41H7104 1 Service Port, EIA-232 DTE
–19 41H7105 1 Service Port, 14.4 Kbps Modem
–20 41H7102 1 LED Panel
–21 92G8546 4 Screw, M4 X 8 Lg
–24 13H8807 1 Power Supply Insulator
–25 41H7109 1 Power Supply
–25A 55H7477 1 DC Power Supply Cable (not shown)
–26 1624743 4 Screw, Hex,M3 X 6 Lg
–27 13H8806 1 Power Supply Cover
–28 1624743 4 Screw, Hex,M3 X 6 Lg
–29 04H8189 1 DRAM SIMM - 4 MB
–29 04H8190 1 DRAM SIMM - 8 MB
–29 41H7107 1 DRAM SIMM - 16 MB
–29 55H7492 1 DRAM SIMM - 32 MB
Appendix C. Parts Listing C-9
