Chapter 8 – Short Messages Commands

Multi-Tech Systems, Inc. CDMA Wireless AT Commands - PN S000294C

55

C

HAPTER

8

-

S

HORT

M

ESSAGES

C

OMMANDS

For SMS messages, in the CDMA system, the PDU mode will not be supported, instead, the Unicode format
message is supported. The Unicode header code will start at 0x80 and above.

Parameters Definition

Call Back Number

Destination Address

Data Coding Scheme, coded like in document [5].

Discharge Time in string format :

“yy/mm/dd,hh :mm :ss”(Year [00-99], Month [01-12],

Day [01-31], Hour, Minute, Second

Encoding

First Octet, coded like SMS-SUBMIT first octet in document [4], default value is 17 for SMS-
SUBMIT

Place of storage in memory.

Language

Length of SMS User Data field.
Memory used to list, read and delete messages (+CMGL, +CMGR and +CMGD).
Memory used to write and send messages (+CMGW, +CMSS).

CBM Message Identifier.

Message Reference.

Originator Address.

Protocol Identifier.

Message Priority

Recipient Address.

Service Center Address

Service Center Time Stamp in string format : “yy/mm/dd,hh :mm :ss”
(Year/Month/Day,Hour:Min:Seconds)

CBM Serial Number

Status of a SMS-STATUS-REPORT (see Chapter 17for possible values)

Status of message in memory.

Type-of-Address of .

Type-of-Address of .

Type-of-Address of .
Number of message locations in .
Number of messages locations in

Timestamp for MT SMS.

Total number of messages locations in .
Total number of messages locations in

Validity Period of the short message, default value is 167
