Chapter 15 – SIM TOOLKIT
Multi-Tech Systems, Inc. CDMA Wireless AT Commands - PN S000294C 121
SIM ToolKit Give Response (+STGR)
Description: This command allows the application/user to select an item in the main menu or to answer the
following proactive commands:
• GET INKEY Key pressed by the user.
• GET INPUT Message entered by the user.
• SELECT ITEM Selected item.
• SETUP CALL User confirmation.
• DISPLAY TEXT User confirmation to clear the message.
It is also possible to terminate the current proactive command session by sending a Terminal Response to
the SIM with the following parameters:
• BACKWARD MOVE Process a backward move
• BEYOND CAPABILITIES Command beyond ME capabilities
• UNABLE TO PROCESS ME is currently unable to process command
• NO RESPONSE No response from the user
• END SESSION User abort.
Values:
0: Item selection in the main menu
1: User confirmation to clear displayed Text.
2: Response for a ‘Get Inkey’
3: Response for a ‘Get Input’
4: Response for a ‘Setup call’
96: Response for a ‘Sel Item’
95: Backward move
96: Command beyond ME capabilities
97: ME currently unable to process command
98: No response from the user
99: User abort
Values when CmdType=0 (Select an item from the main menu)
1: Item selected by the user
2: Help information required by user
Contains the item identifier of the item selected by the user
Values when CmdType=1 (Confirm the display text clearing)
No values
Values when CmdType=2 (Get Inkey)
0: Session ended by user
1: Response given by the user
2: Help information required by user
Contains the key pressed by the user
Values when CmdType=3 (Get Input)
0: Session ended by user
1: Response given by the user
2: Help information required by user
Contains the string of characters entered by the user. For inputs in UCS2 format, the
data are entered in ASCII format. Example: 8000410042FFFF entered, the SIM
receives 0x00 0x41 0x00 0x42 with UCS2 DCS.
